Balconies structure analysis

The balcony is generally a square structure, and the height of the zipper blinds is generally about 3 meters.

With the continuous improvement of people's quality of life, the balcony of the home is getting larger and larger, the width from 2 meters to 10 meters, but the high-rise bungalows, the general elevator is not large, can accommodate up to 3 meters long items, so if you want to use the elevator to get the windbreak curtain into the room, its width can not exceed 3 meters.

The balcony has a single side opening, there are also U-shaped balconies;

Fabric selection

Balcony with zip roller blinds, first of all, we use 5%, 50% open rate outdoor sun fabric, fabric tensile strength must be greater than 2000N/5cm, tear strength greater than 100N, color fastness greater than 8, flame retardant grade greater than B1;

The sun fabric of the balcony zip roller blinds must have good welding strength with the zipper, in order to ensure that the wind resistance is greater than 12 strong winds, we require that each meter of the welded zipper must bear 150kg of tension, and keep it deformation or fall off within a week.

Operation system

Balcony with zip roller blinds, we use electric operation mainly, pull bead as the auxiliary operating system, to meet the needs of different application scenarios. We recommend that the main opening face of the balcony be held down with electric windshields, while the small Windows are fitted with windshields that pull beads or push springs.

Shield system

Since the main element of the balcony is generally a cube structure, we adopted a square shield system that seamlessly integrates with the basic marshal of the balcony;

In order to ensure the overall installation effect, the balcony zip roller blinds is generally 120X120, 120X140 protective cover system, because used in the outdoor, the side cabinet uses 60X4 and 80X60, and the buckle is linked without screws, so as to ensure the appearance is clean and beautiful, but also ensure that the disassembly is convenient;

Product recommendation

Balcony zip roller blinds, if it is a small window, you can directly turn, if more than 4 meters of zipper blinds should be used can be connected zip roller blinds, WR120C,WR120-140 and other models of zip roller blinds;

Especially for balconies with a width of more than 6 meters, the WR120-140 series of zip roller blinds must be used.

Structure design

The system adopts the structure of ultra-wide zipper blinds of topcloth strips, adopts the top installation, and the main body and low rail are connected by a lapel, so that it is easy to transport the parts to the installed balcony;

Super wide zip roller blinds, installation difficulty is increased, in the product uses a special structure, in the case of no disassembly, you can replace the motor.

In order to better present the space of the balcony, sometimes two layers of zip roller blinds are installed, one layer is 50% high-permeability anti-mosquito fabric, and the other layer is 0% full-shading fabric, which can effectively create a full-shading balcony space.

Material Selection

Balcony zip roller blinds, because it is used in the outdoors, all screw materials are at least made of national standard 304 stainless steel, even made of 316 stainless steel, aluminum is made of high-quality aviation aluminum with a thickness of more than 2mm, the surface is sprayed with outdoor powder, and the structural parts are purchased with nylon and fiber engineering plastics; This ensures the corrosion resistance and durability of the zip roller blinds;

Smart Balancer

In order to ensure the flatness of the zip roller blinds of the balcony, the ultra-hard aluminum alloy material is first used, the ultra-thick 63 aluminum tube and 78 double-layer tube are used, and the smart balancer is used in the structure, that is, the fabric guide and the patent technology of the topcloth strip are used.
